型號

軸徑

d

導程

I

珠徑
Da

螺母尺寸

動額定負荷 Ca

靜額定負荷Coa

剛性

kgf/μm

D

A

E

B

L

W

H

X

Q

n

SFH01205-2.8 ★

12

5

2.5

24

40

5

10

30

32

30

4.5

2.8x1

661

1316

19

SFH01210-2.8 ★

10

2.5

24

40

5

10

45

32

30

4.5

2.8x1

642

1287

19

SFH01605-3.8 ★

15

5

2.778

28

48

5

10

37

38

40

5.5

M6

3.8x1

1112

2507

30

SFH01610-2.8 ★

10

2.778

28

48

5

10

45

38

40

5.5

M6

2.8x1

839

1821

23

SFH01616-1.8 ★

16

2.778

28

48

5

10

45

38

40

5.5

M6

1.8x1

552

1137

14

SFH01616-2.8 ★

16

2.778

28

48

5

10

61

38

40

5.5

M6

2.8x1

808

1769

22

SFH01620-1.8 ★

20

2.778

28

48

7

10

58

38

40

5.5

M6

1.8x1

554

1170

14

SFH02005-3.8 ★

20

5

3.175

36

58

7

10

37

47

44

6.6

M6

3.8x1

1484

3681

37

SFH02010-3.8 ★

10

3.175

36

58

7

10

55

47

44

6.6

M6

3.8x1

1516

3833

40

SFH02020-1.8 ★

20

3.175

36

58

7

10

54

47

44

6.6

M6

1.8x1

764

1758

19

SFH02020-2.8 ★

20

3.175

36

58

7

10

74

47

44

6.6

M6

2.8x1

1118

2734

29

SFH02505-3.8 ★

25

5

3.175

40

62

7

10

37

51

48

6.6

M6

3.8x1

1650

4658

43

SFH02510-3.8 ★

10

3.175

40

62

7

12

55

51

48

6.6

M6

3.8x1

1638

4633

45

SFH02525-1.8 ★

25

3.175

40

62

7

12

64

51

48

6.6

M6

1.8x1

843

2199

22

SFH02525-2.8 ★

25

3.175

40

62

7

12

89

51

48

6.6

M6

2.8x1

1232

3421

34

SFH03205-3.8

32

5

3.175

50

80

9

12

37

65

62

9

M6

3.8x1

1839

6026

51

SFH03210-3.8

31

10

3.969

50

80

9

12

57

65

62

9

M6

3.8x1

2460

7255

55

SFH03220-2.8

20

3.969

50

80

9

12

76

65

62

9

M6

2.8x1

1907

5482

43

SFH03232-1.8

32

3.969

50

80

9

12

80

65

62

9

M6

1.8x1

1257

3426

27

SFH03232-2.8

32

3.969

50

80

9

12

112

65

62

9

M6

2.8x1

1838

5329

42

SFH04005-3.8

40

5

3.175

63

93

9

15

42

78

70

9

M8

3.8x1

2018

7589

60

SFH04010-3.8

38

10

6.35

63

93

9

14

60

78

70

9

M8

3.8x1

5035

13943

67

SFH04020-2.8

20

6.35

63

93

9

14

80

78

70

9

M8

2.8x1

3959

10715

54

SFH04040-1.8

40

6.35

63

93

9

14

98

78

70

9

M8

1.8x1

2585

6648

34

SFH04040-2.8

40

6.35

63

93

9

14

138

78

70

9

M8

2.8x1

3780

10341

52

SFH05005-3.8

50

5

3.175

75

110

10.5

15

42

93

85

11

M8

3.8x1

2207

9542

68

SFH05010-3.8

48

10

6.35

75

110

10.5

18

60

93

85

11

M8

3.8x1

5638

17852

79

SFH05020-3.8

20

6.35

75

110

10.5

18

100

93

85

11

M8

3.8x1

5749

18485

87

SFH05050-1.8

50

6.35

75

110

10.5

18

120

93

85

11

M8

1.8x1

2946

8749

42

SFH05050-2.8

50

6.35

75

110

10.5

18

170

93

85

11

M8

2.8x1

4308

13610

65

※ 有標注★記號者可制作 SFNH 滑臺專用規范。
